Specifications
Standard Specifications
- Sidewalls & Floor 10 Gauge Thickness Steel
- Height of Sidewall 24"
- Width Inside Body 73-1/2" & 81-1/2"
- Frame 8" Cold Formed I-Beam
- Tool Box Aluminum Diamond Plate with Storage
- Gate Double Acting with Metering Chains
- Fenders 1/8" Steel Diamond Plate
- Ramps (Aluminum) 15-1/2" Wide x 72" Long
- Hydraulic Lift Scissors Hoist 12' & 14' - Cylinder 10'
- Hydraulic Pump Power Up/Power Down
- Suspension Rubber Ride (low maintenance)
- Brakes Electric (all wheels)
-
Tires & Wheels
9950 lb GVWR - 15" 8 Ply Rated 6-Bolt
12000 lb & 14000 lb GVWR - 16" 10 Ply Rated 8-Bolt
16000 lb GVWR - 17.5" 16 Ply Rated 8-Bolt - Jack 7000 lb 10' & 12' - 12000 lb 14'
- Coupler 2-5/16" Adjustable (4-bolt)
- Safety Chains 3/8" with Latch Hook
- Lights & Wiring LED Lights & Sealed Wire Harness
-
Other Standard Features
Step to Access Inside Bed
D-Rings Inside Bed
Gate Hold Back Latches - Warranty 2 Year Limited (see warranty for details)
Frame Specifications
| Frame & Tongue | Body Sides & Floor | Body Cross Members | Body Main Rails | Fenders |
|---|---|---|---|---|
| One Piece Cold Formed 8″ I-Beam | 10 Gauge Thickness Steel | 3″ Channel | 2″ x 3″ x 3/16″ Tube | 1/8″ Steel Diamond Plate |
Axle Specifications
| GVWR | Axles |
|---|---|
| 9950 lb | 6000 lb with Electric Brakes & Easy Lube Spindles (15″ 6-bolt) |
| 12000 lb | 6000 lb with Electric Brakes & Easy Lube Spindles (16″ 8-bolt) |
| 14000 lb | 7000 lb with Electric Brakes & Easy Lube Spindles (16″ 8-bolt) |
| 16000 lb | 8000 lb with Electric Brakes & Easy Lube Spindles (17.5″ 8-bolt) |
Weight Specifications
| Bumper Pull (estimated weights) | ||||
|---|---|---|---|---|
| Length / Width | 9950 | 12000 | 14000 | 16000 |
| 10′ / 73-1/2″ | 3060 lbs | 3320 lbs | n/a | n/a |
| 10′ / 83-1/2″ | 3340 lbs | 3500 lbs | n/a | n/a |
| 12′ / 83-1/2″ | 3500 lbs | 3760 lbs | 3900 lbs | n/a |
| 14′ / 83-1/2″ | n/a | 3900 lbs | 3990 lbs | 4480 lbs |
| Gooseneck (estimated weights) | ||||
|---|---|---|---|---|
| Length / Width | 12000 | 14000 | 16000 | |
| 10′ / 73-1/2″ | n/a | n/a | n/a | |
| 10′ / 83-1/2″ | n/a | n/a | n/a | |
| 12′ / 83-1/2″ | 4350 lbs | 4510 lbs | n/a | |
| 14′ / 83-1/2″ | 4660 lbs | 4820 lbs | 5240 lbs | |
Options
- Available Ratings - 9950, 12000, 14000 & 16000 GVWR
- Pintle Ring
- Tarp
- Stake Pockets
- Trip Lever (forward pull) for Tailgating
- Jack Upgrade - 7K to 12K (12K Standard on 14' Bumper Pulls & All Goosenecks)
- Jack Upgrade - Hydraulic Jack (power up/ power down)
- Wireless Remote
- Spare Tire & Wheel
- Pallet Fork Holders
Colors
- Red
- Black
- Charcoal
Dump Body Volume
| Length | Width | Volume (cubic yards) |
|---|---|---|
| 10' | 73-1/2" | 4.5 |
| 10' | 81-1/2" | 5 |
| 12' | 81-1/2" | 6 |
| 14' | 81-1/2" | 7 |
